Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-152
035 779 FAX FWD
document
change error
FAX forward document
change error
Fax Communication Error 035-
779
Fax forward document error
Job canceled.
* Caution screen with [Close]
button
Replace the
Fax Board.
035 781 Detect busy tone after
dialing.
Target Fax Busy 035-781
Busy tone detected
Job canceled.
* Caution screen with [Close]
button
Replace the
Fax Board.
035 792 JM Not Detection JM undetected Fax Communication Error 035-
792
Joint Menu signal not Detected
Job canceled.
Please try again.
* Caution screen with [Close]
button
Replace the
Fax Board.
035 793 Digital Line
Detection
Connected to digital line
and cannot connect.
(Detect when connecting
to line)
Fax Communication Error 035-
793
Digital line detected, an anolog
line is required
Job canceled. Please confirm fax
line is Anolog and not Digital. If
error persists, contact phone
provider.
* Caution screen with [Close]
button
Replace the
Fax Board.
041 340 IOT NVRAM Error Detect NVRAM Error Engine NVRAM Error 041-340
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Code:xxxxxxxxh
Page 2-178
041 347 IOT I/F Failure MCU Internal Error(I/F
part)
Engine Controller Error 041-347
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
MCU Board.
WorkCentre 6605 Error Code List
Chain Link Error Error Details Control Panel Messages
FIP
location

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
