Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-154
050 112 MSI Paper Jam Detected Zone
MSI
Paper Jam
Open Bypass Tray and Tray 1, and
remove any jammed paper.
1. Pull out
papers on
the Bypass
Tray
2. Pull out
Bypass Tray
3. Pull out
Tray1
4. Remove
any jammed
paper
5. Push
Tray1 back
in
6. Push
Bypass Tray
back in
050 121 IOT Remain Zone
1T JAM
Paper Jam Detected Zone
1T
Paper Jam
1. Pull out Tray 1 and remove any
jammed paper.
2. Insert Tray 1 and press [Start].
Open Tray1
& Remove
paper
050 122 IOT Remain Zone
2T JAM
Paper Jam Detected Zone
2T
Paper Jam
Pull out Tray 2 and remove any
jammed paper.
Open Tray2
& Remove
paper
WorkCentre 6605 Error Code List
Chain Link Error Error Details Control Panel Messages
FIP
location

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
