Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-155
050 129 IOT Rear Cover
and MSI
Paper Jam Detected Zone
IOT RearCover and MSI
Paper Jam
Pull out Bypass Tray, Tray 1, and
Open Rear Cover to remove any
jammed paper.
1. Pull out
papers on
the Bypass
Tray
2. Pull out
Bypass Tray
3. Pull out
Tray1
4. Remove
any jammed
paper
5. Push
Tray1 back
in
6. Push
Bypass Tray
back in
7. Open the
Rear Cover if
cannot
remove any
jammed
paper
8. Remove
any jammed
paper
9. Close the
Rear Cover
061 370 IOT ROS Failure Detect ROS Failure Laser Unit Error 061-370
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Code:xxxxxxxxh
Page 2-179
062 320 Scanner Error Scanning error Scanner Error 062-320
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Page 2-209
062 321 Unexecutable error.
(carriage is at the locked
position, etc.)
Scanner Error 062-321
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Page 2-209
WorkCentre 6605 Error Code List
Chain Link Error Error Details Control Panel Messages
FIP
location

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
