Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-156
062 322 Parameter error Scanner Error 062-322
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Page 2-209
062 360 HPSensor Error Carriage home position
error
Scanner Home Position Sensor
Error 062-360
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Page 2-209
062 371 IIT failure Lamp error Scanner Lamp Error 062-371
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Page 2-209
062 393 CcdAsic Error CcdAsic communication
error
Scanner Error 062-393
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Page 2-209
062 790 Copy Limit Copy limit Copy Limit Error
Last sheet not copied.
* Caution screen with [Close]
button
Page 2-209
071 100 IOT Tray1
Misfeed JAM
Detect Tray1 Misfeed JAM no message Page 2-192
072 100 IOT Tray2
Misfeed JAM
Detect Tray2 Misfeed no message Page 2-193
072 101 IOT Path2 SNS
On JAM
Detect Path2 SNS On JAM no message Page 2-193
072 211 IOT Option
Feeder2 Failure
Detect Feeder2 Failure Tray 2 Error 072-211
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Code:xxxxxxxxh
Page 2-178
075 100 MSI Misfeed JAM Detect VSYNC On
JAM(TBD)
no message Page 2-195
075 910 MSI Detached MSI Detached Bypass Tray Missing 075-910
Insert Bypass Tray.
Page 2-196
077 101 VSYNC?ON?JAM Detect VSYNC On JAM no message Replace the
MCU Board.
WorkCentre 6605 Error Code List
Chain Link Error Error Details Control Panel Messages
FIP
location

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
