Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-157
077 104 RegOff JAM Detect RegOff JAM no message Page 2-197
077 106 Exit ON JAM Detect Exit ON JAM no message Page 2-197
077 107 Duplex ON JAM Detect Duplex ON
JAM(TBD)
no message Page 2-198
077 108 ExitOff ealry JAM Detect ExitOff early JAM no message Page 2-198
077 109 ExitOff JAM Detect IOT Exit Sensor Off
JAM
no message Page 2-198
077 215 IOT Duplexer
Error
Duplex Unit Error 077-215
Reseat Duplex Unit and Power
Off/On the Printer.
If this failure occurs again, please
contact customer support.
-
077 217 Duplex Mis-
configuration
Duplex Mis-configuration Duplexer Error 077-217
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
MCU Board.
077 300 IOT Cover Front
Open
FrontCover Open.
Beep sounds after
FrontCover remains open
for 3 minutes.
Front Cover Open
Close Front Cover.
Page 2-199
077 301 <IOT Side Cover
Open>
Side Cover is open. Right Side Door Open
Close Right Side Door.
Page 2-199
077 304 IOT Cover Rear
Open
Rear Cover Open Rear Cover Open
Close Rear Cover.
Page 2-200
077 312 Tray Configure
Error
Combination of trays was
illegal.
Tray Configuration Error 077-312
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Code:xxxxxxxxh
-
091 400 IOT Waste Toner
Box Near Life
Detect Waste Toner Box
Near Life
XXXXXXXXXXXXXXXX
Replace Waste Toner Box, Near Full
Page 2-200
091 402 IOT Drum
Cartridge Kit Life
Pre Warning
Detect Drum Life Warning XXXXXXXXXXXXXXXX
Imaging Unit Kit Near End of Life
Replace the
Imaging
Unit.
091 911 IOT Waste Toner
Box Life Over
Detect Waste Toner Box
Life Over
Waste Toner Box End of Life
Open the Right Side Door.
Then, replace the Waste Toner Box.
Page 2-200
WorkCentre 6605 Error Code List
Chain Link Error Error Details Control Panel Messages
FIP
location

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
