Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-158
091 914 IOT K Drum
Comm Fail
Detect Black Drum Comm
Fail
Black Imaging Unit Error 091-
914
Open the Right Side Door.
Then, reseat Black Imaging Unit or
replace the Imaging Unit Kit.
Page 2-201
091 915 DRUM UnitK
CRUM Data
Broken Fail
Wrong data in CRUM of
drum K
Black Imaging Unit Error 091-
915
Open the Right Side Door.
Then, reseat Black Imaging Unit or
replace the Imaging Unit Kit.
Page 2-203
091 917 IOT Y Drum
Comm Fail
Detect Yellow Drum Comm
Fail
Yellow Imaging Unit Error 091-
917
Open the Right Side Door.
Then, reseat Yellow Imaging Unit
or replace the Imaging Unit Kit.
Page 2-201
091 918 IOT M Drum
Comm Fail
Detect Magenta Drum
Comm Fail
Magenta Imaging Unit Error
091-918
Open the Right Side Door.
Then, reseat Magenta Imaging
Unit or replace the Imaging Unit
Kit.
Page 2-202
091 919 IOT C Drum
Comm Fail
Detect Cyan Drum Comm
Fail
Cyan Imaging Unit Error 091-
919
Open the Right Side Door.
Then, reseat Cyan Imaging Unit or
replace the Imaging Unit Kit.
Page 2-203
091 920 DRUM Y CRUM
Data Broken Fail
Wrong data in CRUM of
drum Y
Yellow Imaging Unit Error 091-
920
Open the Right Side Door.
Then, reseat Yellow Imaging Unit
or replace the Imaging Unit Kit.
Page 2-204
091 921 IOT K Drum
Detached
Black Black Imaging Unit Missing
Open the Right Side Door.
Then, insert the Black Imaging
Unit.
Reinsert the
Black
Imaging
Unit.
091 922 DRUM M CRUM
Data Broken Fail
Wrong data in CRUM of
drum M
Magenta Imaging Unit Error
091-922
Open the Right Side Door.
Then, reseat Magenta Imaging
Unit or replace the Imaging Unit
Kit.
Page 2-204
