Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-159
091 923 DRUM C CRUM
Data Broken Fail
Wrong data in CRUM of
drum C
Cyan Imaging Unit Error 091-
923
Open the Right Side Door.
Then, reseat Cyan Imaging Unit or
replace the Imaging Unit Kit.
Page 2-204
091 927 IOT Y Drum
Detached
Yellow Yellow Imaging Unit Missing
Open the Right Side Door.
Then, insert the Yellow Imaging
Unit.
Reinsert the
Yellow
Imaging
Unit.
091 928 IOT M Drum
Detached
Magenta Magenta Imaging Unit Missing
Open the Right Side Door.
Then, insert the Magenta Imaging
Unit.
Reinsert the
Magenta
Imaging
Unit.
091 929 IOT C Drum
Detached
Cyan Cyan Imaging Unit Missing
Open the Right Side Door.
Then, insert the Cyan Imaging
Unit.
Reinsert the
Cyan
Imaging
Unit.
091 935 IOT Drum
Cartridge Kit Life
Over
Detect Drum Cartridge Kit
Life Over
Imaging Unit Kit End of Life
Open the Right Side Door.
Then, replace the Imaging Unit Kit.
Replace the
Imaging
Unit.
091 960 IOT X CRUM ID
Error
Detect Y Drum CRUM ID
Warning
Invalid Imaging Unit
Open the Right Side Door.
Then, reseat/replace the Yellow
Imaging Unit.
Page 2-204
091 961 IOT X CRUM ID
Error
Detect M Drum CRUM ID
Warning
Invalid Imaging Unit
Open the Right Side Door.
Then, reseat/replace the Magenta
Imaging Unit.
Page 2-204
091 962 IOT X CRUM ID
Error
Detect C Drum CRUM ID
Warning
Invalid Imaging Unit
Open the Right Side Door.
Then, reseat/replace the Cyan
Imaging Unit.
Page 2-204
091 963 IOT X CRUM ID
Error
Detect K Drum CRUM ID
Warning
Invalid Imaging Unit
Open the Right Side Door.
Then, reseat/replace the Black
Imaging Unit.
Page 2-203
