Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-200
077-304 IOT Cover Rear Open
091-400 IOT Waste Toner Box Near Life
091-911 IOT Waste Toner Box Life Over
Step Check Yes No
Possible causative parts:
• Rear Interlock Switch (PL19.1.21)
• LVPS (PL18.1.34)
1 Check the Rear Interlock Switch operation
Execute Digital Input diagnostic test 041-301, and check the
Rear Interlock Switch operation.
Does it function normally?
Replace the MCU
Board.
Go to step 2.
2 Check the Rear Interlock Switch connection
Check the connection between the Rear Interlock Switch and
the LVPS.
Is P/J41 connected securely?
Go to step 3. Connect P/J41
securely.
3 Check after replacing the Rear Interlock Switch
Replace the Rear Interlock Switch.
Does the error still occur?
Replace the LVPS. Finished.
Step Check Yes No
Possible causative parts:
• Toner Full Sensor (PL4.1.17)
• MCU Board (PL18.1.13)
1 Check the Toner Full Sensor operation
Execute Digital Input diagnostic test 094-202, and check the
Toner Full Sensor operation.
Does it function normally?
Replace the MCU
Board.
Go to step 2.
2 Check the Toner Full Sensor connection
Check the connection between the Toner Full Sensor and the
MCU Board.
Are P/J203 and P/J29 connected securely?
Go to step 3. Connect P/J203
and P/J29
securely.
3 Check the power to the Toner Full Sensor (+5 VDC)
Check if the voltage between the MCU Board ground and the
P/J29-20 pin is about +5 VDC.
Replace the
Toner Full Sensor.
Refer to
page 2-223.

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
