Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-199
077-300 IOT Cover Front Open
077-301 IOT Side Cover Open
Step Check Yes No
Possible causative parts:
• Front Cover Sensor (PL18.1.45)
• MCU Board (PL18.1.13)
1 Check the Front Cover Sensor operation
Execute Digital Input diagnostic test 041-302, and check the
Front Cover Sensor operation.
Does it function normally?
Replace the MCU
Board.
Go to step 2.
2 Check the Front Cover Sensor connection
Check the connection between the Front Cover Sensor and
the MCU Board.
Are P/J145 and P/J14 connected securely?
Go to step 3. Connect P/J145
and P/J14
securely.
3 Check the power to the Front Cover Sensor (+5 VDC)
Check if the voltage between the MCU Board ground and the
P/J14-9 pin is about +5 VDC.
Replace the Front
Cover Sensor.
Refer to
page 2-223.
Step Check Yes No
Possible causative parts:
• Door Interlock Switch (PL19.1.21)
• LVPS (PL18.1.34)
1 Check the Door Interlock Switch operation
Execute Digital Input diagnostic test 041-300, and check the
Door Interlock Switch operation.
Does it function normally?
Replace the MCU
Board.
Go to step 2.
2 Check the Door Interlock Switch connection
Check the connection between the Door Interlock Switch and
the LVPS.
Is P/J42 connected securely?
Go to step 3. Connect P/J42
securely.
3 Check after replacing the Door Interlock Switch
Replace the Door Interlock Switch.
Does the error still occur?
Replace the LVPS. Finished.

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
