Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-196
075-910 MSI (Bypass Tray) Detached
Step Check Yes No
Possible causative parts:
• Bypass Tray No Paper Sensor (PL13.2.4)
• Bypass Tray Cover Assembly (PL13.3.2)
• Bypass Tray Harness Assembly (PL13.2.5)
• MCU Board (PL18.1.13)
1 Check the Bypass Tray installation
Is the Bypass Tray installed properly?
Go to step 2. Install the
Bypass Tray
properly.
2 Check the Bypass Tray Cover Assembly
Is the Bypass Tray Cover Assembly broken?
Replace the
Bypass Tray
Cover Assembly.
Go to step 3.
3 Check the Bypass Tray No Paper Sensor operation
Execute Digital Input diagnostic test 071-102, and check the
Bypass Tray No Paper Sensor operation.
Does the Bypass Tray No Paper Sensor function normally?
Replace the MCU
Board.
Go to step 4.
4 Check the connections between Bypass Tray No Paper Sensor
and the MCU Board
Check the connection between the Bypass Tray No Paper
Sensor and the MCU Board.
Are P/J211 and P/J21 connected securely?
Go to step 5. Connect P/J211
and P/J21
securely.
5 Check the Bypass Tray Harness Assembly continuity.
Is each cable of P/J211<=>P/J21 continuous?
Go to step 6. Replace the
Bypass Tray
Harness
Assembly.
6 Check the power to the Bypass Tray No Paper Sensor
(+5 VDC)
Check if the voltage between the MCU Board ground and the
P/J21- 1 pin is about +5 VDC.
Replace the
Bypass Tray No
Paper Sensor.
Refer to
page 2-223.

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
