Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-166
116 356 HDD Overwrite
Error
Error has occurred during
HDD overwrite.
Hard Disk Error 116-356
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
IP Board.
116 361 PCI Bus#0 Error
Detected
PCI Bus#0 Uncorrectable
Error Detected
* Connected with
RemoraEX(x4 port)
Controller PCI Error 116-361
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
IP Board.
116 362 PCI Bus#0 Host
Bridge Controller
Error
PCI Bus#0 Host Bridge
Controller Error
(Connected with
RemoraEX port)
Controller PCI Error 116-362
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
IP Board.
116 363 PCI Bus#1 Host
Bridge Controller
Error
PCI Bus#1 Host Bridge
Controller Error
(Connected with
RemoraEX port)
Controller PCI Error 116-363
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
IP Board.
116 364 Timer Fail Timer error is detected Controller Clock Error 116-364
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
IP Board.
116 366 PCI Bus#1 Error
Detected
PCI Bus#1 Uncorrectable
Error Detected
* Connected with
RemoraEX(x1 port)
Controller PCI Error 116-366
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
IP Board.
116 368 PCI Error
Messages
received from
Bus#0-Device#1
RemoraEX PCI x1 port
Error
* DeviceID 0x65 (x1)
Controller PCI Error 116-368
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
IP Board.
116 369 PCI Error
Messages
received from
Bus#0-Device#0
RemoraEX PCI x4 port
Error
* DeviceID 0x64 (x4)
Controller PCI Error 116-369
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
IP Board.
116 390 ESS NVRAM1
SIZE And ID
Check Fail
Detected by consistency
check between NVRAM
size requested by the
system and actual size and
consistency check of ID
recorded at the first
power-on.
Controller NVRAM Error 116-390
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
IP Board.
WorkCentre 6605 Error Code List
Chain Link Error Error Details Control Panel Messages
FIP
location

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
