Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-165
116 326 Reserved(For
NVRAM2)
Controller NVRAM Error 116-326
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
IP Board.
116 327 ESS Instruction
Cache Error
CPU instruction cache
error
Controller Error 116-327
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
IP Board.
116 328 ESS Data Cache
Error
CPU data cache error Controller Error 116-328
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
Fuser
Assembly.
116 343 ASIC Fail TBD Controller ASIC Error 116-343
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
IP Board.
116 350 On Board
Network
Communication
Fail
Communication fail
between 1 CPU network
and ESS F/W.
Network Error 116-350
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
IP Board.
116 351 On Board
Network Ethernet
BIST parity/RAM
R/W Error
Network Error 116-351
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
IP Board.
116 352 On Board
Network Internal
Loopback Error
Network Error 116-352
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
IP Board.
116 353 ESS HD Fail Detect HDD Error Hard Disk Error 116-353
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
IP Board.
116 355 On Board
Network Fatal
Error
Network Error 116-355
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
IP Board.
WorkCentre 6605 Error Code List
Chain Link Error Error Details Control Panel Messages
FIP
location

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
