Xerox WorkCentre 6605

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-185
093-951 IOT X CRUM Error (M Toner)
Step Check Yes No
Possible causative parts:
• Magenta Toner Cartridge (PL5.1.9)
• Dispenser Assembly M (PL5.1.5)
• Top Harness Assembly (PL18.2.5)
• MCU Board (PL18.1.13)
1 Check the Toner Cartridge installation
Is the connection part between the CRUM and the Dispenser
Assembly M inside the Magenta Toner Cartridge clean
(without any foreign objects)?
And, is the Magenta Toner Cartridge installed properly?
Go to step 2. Reinstall the
Magenta Toner
Cartridge.
2 Check the CRUM of the Toner Cartridge
Is the connection terminal of the CRUM inside the Magenta
Toner Cartridge broken?
Replace the
Magenta Toner
Cartridge.
Go to step 3.
3 Check the Dispenser Assembly M
Is the connection terminal of the Dispenser Assembly M
broken?
Replace the
Dispenser
Assembly M.
Go to step 4.
4 Check the Dispenser Assembly M connection
Check the connection between the Dispenser Assembly M
and the MCU Board.
Are P/J192 and P/J19 connected securely?
Go to step 5. Connect P/J192
and P/J19
securely.
5 Check the continuity between the Dispenser Assembly M and
the MCU Board
Is each cable of P/J192<=>P/J19 continuous?
Replace the MCU
Board.
Replace the Top
Harness
Assembly.
