093-952 IOT X CRUM Error (C Toner)
Step Check Yes No
Possible causative parts:
• Cyan Toner Cartridge (PL5.1.10)
• Dispenser Assembly C (PL5.1.6)
• Top Harness Assembly (PL18.2.5)
• MCU Board (PL18.1.13)
1 Check the Toner Cartridge installation
Is the connection part between the CRUM and the Dispenser
Assembly C inside the Cyan Toner Cartridge clean (without
any foreign objects)?
And, is the Cyan Toner Cartridge installed properly?
Go to step 2. Reinstall the
Cyan Toner
Cartridge.
2 Check the CRUM of the Toner Cartridge
Is the connection terminal of the CRUM inside the Cyan
Toner Cartridge broken?
Replace the Cyan
Toner Cartridge.
Go to step 3.
3 Check the Dispenser Assembly C.
Is the connection terminal of the Dispenser Assembly C
broken?
Replace the
Dispenser
Assembly C.
Go to step 4.
4 Check the Dispenser Assembly C connection
Check the connection between the Dispenser Assembly C
and the MCU Board.
Are P/J193 and P/J19 connected securely?
Go to step 5. Connect P/J193
and P/J19
securely.
5 Check the continuity between the Dispenser Assembly C and
the MCU Board
Is each cable of P/J193<=>P/J19 continuous?
Replace the MCU
Board.
Replace the Top
Harness
Assembly.
