Xerox WorkCentre 6605 Service Manual

Image Quality
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
3-6
8 Check dirt and foreign substances on the CTD Sensor surface.
Is the CTD Sensor Assembly Sensor surface dirty, or are there any
foreign substances on the surface?
Clean the CTD
Sensor surface.
See “Cleaning
the Color Toner
Density
Sensors” on
page 6-11.
Go to action 9.
9 Check the Transfer Roller.
Is Transfer Roller not contaminated, damaged, or worn, and does it
work correctly?
Go to action 10. Reinstall
Transfer Roller.
10 Check the Transfer Roller.
Is Transfer Roller not contaminated, damaged, or worn, and does it
work correctly?
Go to action 11. Replace
Transfer Roller.
11 Check the Transfer HVPS Board connector connection.
Is the Transfer HVPS Board connector connected correctly?
Go to action 12. Connect the
connector.
12 Check the Development HVPS Board connector connection.
Is the Development HVPS Board connector connected correctly?
Replace the
Development
HVPS Board.
Connect the
connector.
Action Yes No

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
