Xerox WorkCentre 6605 Service Manual

Wiring
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
7-13
271 F-112/I-182 Connects Feeder Drawer 1 Harness Assembly and Main Harness Assembly
271 I-182 Connects Feeder Drawer 1 Harness Assembly and Main Harness Assembly
281 E-152 Connects Fuser and Heater Harness Assembly
311 E-108 Connects Main Motor and Top Harness Assembly
312 E-111 Connects Paper Transport Motor and Top Harness Assembly
331 E-109 Connects Deve Motor and Drive Harness Assembly
392 E-126 Connects CST Feed Clutch and Regi Harness Assembly
401 D-162 Connects IP Board and Top Harness Assembly
419 G-183 Connects IP Board and Top Harness Assembly
420 G-183 Connects 550 Option Feeder Board and Feeder Drawer 1 Harness Assembly
421 F-183 Connects 550 Option Feeder Board and C2 Turn Harness Assembly
422 F-183 Connects 550 Option Feeder Board and C2 Size Harness Assembly
423 G-183 Connects 550 Option Feeder Board and Feeder Motor Harness Assembly
431 H-140 Connects Laser Unit and Top Harness Assembly
501 C-157 Connects LVPS and Top Harness Assembly
503 C-157 Connects LVPS and Main Fan
507 H-157 Connects LVPS and Top Harness Assembly
508 H-157 Connects LVPS and Top Harness Assembly
509 B-158 Connects LVPS and Top Harness Assembly
810 A-164 Connects IP Board and USB Hub Board
820 E-107 Connects USB Hub Board and IP Board
830 E-107 Connects USB Hub Board and Control Panel Assembly
902 C-166 Connects IP Board and FAX Board
1302 D-165 Connects IP Board and Speaker
1401 A-162 Connects IP Board and Scanner Assembly
1501 D-162 Connects IP Board and Scanner Assembly
1502 C-162 Connects IP Board and Scanner Assembly
1821 C-173 Connects Transfer HVPS and HVPS Harness Assembly
4201 E-184 Connects C2 Turn Clutch and C2 Turn Harness Assembly
4202 E-184 Connects No Paper Harness Assembly and C2 Turn Harness Assembly
4203 D-182 Connects C2 No Paper Sensor and No Paper Harness Assembly
P/J Coordiates Remarks

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
