ABB IRB 6700 - Page 126

3HAC 8225-1/04
!
xx1300001083
Instruction label
Brake release
Moving robot
Brake release buttons
D
Oil specification labelE
Grease specification labelF
Complete oil specificationG
3HAC 9526-1/04
!
xx1300001086
Warning label
Do not dismantle
Stored energy
H
3HAC 4431-1/06
!
xx1300001087
Warning label
Heat
J
3HAC 9191-1/02
!
xx1300001088
Warning label
Tip risk when loosening bolts
K
5
1
2
3
4
6
0
1
3HAC 17804-1/02
!
xx1300001089
Warning label
Moving robot
Shut off with handle
Before dismantling see product manual
L
Continues on next page
