ABB IRB 6700 - Recommended Transport Support

Recommended transport support
Always use the recommended transport support when transporting a robot with
tool.
IRB 6700
220
250
R
90
R
110
200
30
65
130
( 10 )
R
3
M10
( 52
)
( 62 )
B
50
50
40
18
60
12
R
20
30°
A
5
IRB6700
2.65 2.8 3.05 3.2
Lower
arm L
1135 1280 1135 1280
A
1000 1160 630 860
B
21 21 21 21
xx1300001603
66 3HAC044266-001 Revision: -
© Copyright 2013 ABB. All rights reserved.
2 Installation and commissioning
2.3.1 Robot transportation precautions
Continued
