ABB IRB 6700 - Water and Air Connectors

Tightening torque (Nm)
Class 12.9, lubricated
i
Tightening torque (Nm)
Class 10.9, lubricated
i
Dimension
950790M24
i
Lubricated with Molycote 1000, Gleitmo 603 or equivalent
Water and air connectors
The following table specifies the recommended standard tightening torque for
water and air connectors when one or both connectors are made of brass.
Tightening torque Nm -
Max.
Tightening torque Nm -
Min.
Tightening torque Nm -
Nominal
Dimension
158121/8
2010151/4
2515203/8
5030401/2
9055703/4
