3.3.10 Inspecting, mechanical stop pin, axis 1
WARNING
Mechanical stop pin can not be mounted on robot if option 810-1 Electronic
Position Switch is used.
Location of mechanical stop pin
The mechanical stop axis 1 is located at the base as shown in the figure.
xx1200001073
Required equipment
Visual inspection, no tools are required.
