Guide sleeve
xx1000001055
Guide sleeve protected from corrosionA
Base plate, grooves and holes
The illustration below shows the orienting grooves and guide sleeve holes in the
base plate.
xx0300000045
Guide sleeve holes (2 pcs)A
Orienting grooves (3 pcs)B
Continues on next page
3HAC044266-001 Revision: - 75
© Copyright 2013 ABB. All rights reserved.
2 Installation and commissioning
2.4.3 Securing the base plate
Continued
