NoteAction
xx1300000477
Remove the stop pin.5
Refitting the stop pin
NoteAction
xx1300000477
Fit the stop pin.1
xx1300000476
Secure the stop pin with the set screw, cup
point.
Locking liquid (Loctite 243) on screw.
2
M10x20
378 3HAC044266-001 Revision: -
© Copyright 2013 ABB. All rights reserved.
4 Repair
4.6.4 Replacing the stop pin
Continued
