ABB IRB 6700 - Turning Radius

Turning radius
R2
R1
1
7
0
°
1
7
0
°
xx1300001082
R2R1Robot variant
2650 mm920 mmIRB 6700 - 235/2.65
2794 mm958 mmIRB 6700 - 205/2.80
3056 mm1109 mmIRB 6700 - 175/3.05
3200 mm1067 mmIRB 6700 - 150/3.20
3HAC044266-001 Revision: - 59
