4.6.4 Replacing the stop pin
Location of the stop pin
The stop pin is located as shown in the figure.
xx1300000475
Spare part
NoteArt. no.Equipment, etc.
See Product manual, spare
parts - IRB 6700.
Stop pin
Required tools and equipment
NoteArticle numberEquipment, etc.
Content is defined in section Standard
toolkit on page 559.
-Standard toolkit
Continues on next page
376 3HAC044266-001 Revision: -
© Copyright 2013 ABB. All rights reserved.
4 Repair
4.6.4 Replacing the stop pin
