Inspecting, fork lift device set
Use this procedure to inspect the fork lift device set.
NoteAction
DANGER
Turn off all:
• electric power supply
• hydraulic pressure supply
• air pressure supply
to the robot, before entering the robot working area.
1
Check the fork lift devices for damage.2
Check attachment screws for deformation and other
type of damage.
3
Make sure fork lift device set is properly attached.4
Correct tightening torque, fork lift devices:
• 280 Nm
Art. no. is specified in Required
equipment on page 130.
If any damage is detected, the fork lift device and
attachment screws must be replaced!
Correct attachment screws:
• M12x70 quality 12.9 Gleitmo 603 (2 pcs per
additional mechanical stop)
5
3HAC044266-001 Revision: - 133
© Copyright 2013 ABB. All rights reserved.
3 Maintenance
3.3.12 Inspecting the fork lift device set
Continued
