NoteAction
If possible, observe the recommenda-
tions specified in section Recommenda-
tions, quality on page 76. ABB does not
assume any responsibility for other
foundation qualities, due to great vari-
ations in the foundation properties.
Use the base plate as a template and drill 16
attachment holes as required by the selected
bolt dimension.
5
Shown in figure Base plate, grooves and
holes on page 75.
Fit the base plate and use the levelling bolts
to level the base plate.
6
If required, fit strips of sheet metal underneath
the base plate to fill any gaps.
7
Secure the base plate to the foundation with
screws and sleeves.
8
Maximum allowed deviation all over the
base plate, from one contact surface to
the other: 0.2 mm.
Recheck the four contact surfaces on the
base plate to make sure the base plate is level
and flat.
9
If it is not, use pieces of sheet metal or similar
to bring the base plate to a level position.
3HAC044266-001 Revision: - 77
© Copyright 2013 ABB. All rights reserved.
2 Installation and commissioning
2.4.3 Securing the base plate
Continued
