QSFP Optical Transceivers
Management
Information about the pluggable fiber-optic transceiver itself, the operating status, and
network operating conditions can be obtained using the management software.
l Features
l Features — QSFPOptical Transceivers
QSFP Optical Transceivers
Features 103
Color Coding 104
QSFP28/103G/PSM4/SM/MPO 104
QSFP28/112G/AOC/xxxx 106
QSFP28/112G/LR4/SM/LC 108
QSFP28/112G/SR4/MM/MPO 110
Features
l Class 1 Laser safety compliance
l Low EMI metallic enclosure
l Uncooled or cooled laser transmitter (depending on the type)
l Transmit disable and loss-of signal functions
l Multi-rate capabilities
l Multi-protocol compliant
l Very low jitter
l Low power dissipation
l EEPROM of each fiber-optic transceiver includes information about the transceiver
itself (vendor code, wavelength, data rates and other relevant factory parameters), as
well as information specifically from ADVA Optical Networking (device code, serial
number, etc.). You can query the transceiver to make sure it is the right one for the
intended application.
l On board digital diagnostics that provide remote monitoring capability
l Measurements and real-time monitoring of:
o
Rx optical input power (analog) [dBm]
o
Tx optical output power (analog) [dBm]
o
Transceiver temperature (analog) [C]
o
Transceiver supply voltage (analog) [mV]
