Power Cables
Cable Variant Market
Plastic Insulation
Color
Wire Function Voltage Use
CBL/DC/1000/4AWG10/SUB-
D/GR-BL
(Sales Item Number
1036800024)
ETSI Gray DCnegative
conductor
–48 V to negative (-)
terminal
Blue DC positive
conductor
0 V
(return)
to positive (+)
terminal
CBL/DC/1000/4AWG8/SUB-
D/RD-BK
(Sales Item Number
1036800026)
North
America
Red DCnegative
conductor
–48 V to negative (-)
terminal
Black DC positive
conductor
0 V
(return)
to positive (+)
terminal
AC Power Cable Specifications
Overview 158
Number of ACPower Cables 159
CBL/AC/250/LA-C19 159
Overview
To connect an FSP 3000 C to line power, use a detachable, flexible AC power cable with
suitable electric and insulation ratings in accordance with your local safety standards.
The power cable and the assembled connectors must bear the safety agency certification
mark for the specific region or country intended for installation.
The following table outlines the minimum requirements for AC power cables.
Female coupler AC Appliance Coupler according to IEC/EN 60320/C19
Power cable — North
America
l Plug type: NEMA 5-15P
l Wall plug rating: 125 VAC, 15 A
l Device plug: IEC 60320 C19, left angled
l Minimum power cable rating: SJTW 14AWG*3C, 125
VAC, 15 A, with hot, neutral and ground conductors,
UL, C-UL (CSA)
Power cable —
Continental Europe
1
l Plug type: CEE 7/7
l Wall plug rating: 250 VAC, 10 A
l Minimum power cable rating: 250 VAC, 10 A, H05VV-F,
105°C, 3-pole
Power cable — United
Kingdom
l Plug type: BS1363
l Wall plug rating: 250 VAC, 10 A
l Minimum power cable rating: 250 VAC, 10 A, H05VV-F,
105°C
l 3-pole fuse type: 10 A
Power cable —
International
l Plug type: According to your local and national electrical
codes with L, N and PE pin
l Wall plug rating: 250 VAC, 10 A
l Minimum power cable rating: 250 VAC, 10 A
158 FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016)
