Adva FSP 3000 - Interfaces; Auxiliary Interface; Client Interface

AM-S20H-2
l Limited bi-directional optical access to network interface via the auxiliary interface,
allowing access to each network fiber
l Ultra-fast transient suppression
l Monitor ports allowing access to the amplifier input and output
l Is field replaceable
l Interfaces
l Signal Path
l Handling Modules
l Electrostatic Discharge Damage Prevention and Warning
Interfaces
Auxiliary Interface 67
Client Interface 67
Monitor Interface 68
Network Interface 68
l Overview
l Port Pinouts
l Specifications
Auxiliary Interface
Number of auxiliary ports 1
Type of auxiliary interface
l Limited bi-directional optical access to N-T (Aux-T
to N-T)
l Limited bi-directional optical access to N-R (Aux-R
to N-R)
Optical connector LC/APC
Access
An aux port filter is present on both N-T and N-R,
allowing access to the network fiber for wavelengths of
approximately 1650 nm
Client Interface
Number of client ports 1
Type of client interface Bi-directional optical
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 67
