Installing the ECM-2
This procedure assumes that:
l The shelf is properly grounded to the rack; and
l The shelf and module have been properly inspected.
1. Verify that you are properly grounded with an anti-static wrist strap or heel strap
connected to the grounded ESDjack.
2. Hold the ECM-2 with the faceplate toward you and the levers extended.
3. Align the ECM-2 edges with the guides of the shelf slot.
4. Lift out on the levers and gently apply pressure to the bottom of the faceplate while
pushing the module into the slot.
5. Push on the faceplate to fully seat the module.
6. Press down on the locking levers to secure the module and connect it to the
backplane. The module is completely inserted when its faceplate is flush with the
faceplates of the adjacent modules and the shelf panels.
7. When the ECM-2 is inserted completely, hand tighten the thumb screws to prevent
inadvertent dislodging.
8. Use a Torx T10 screwdriver to gently tighten the thumb screws. Do not overtighten.
l Electrostatic Discharge Damage Prevention and Warning
l ECM-2
Installing the FTM-2 in the SH12
This procedure assumes that:
l The shelf is properly grounded to the rack; and
l The shelf and module have been properly inspected.
1. Verify that you are properly grounded with an anti-static wrist strap or heel strap
connected to the grounded ESDjack.
2. Hold the FTM-2 upright with the faceplate toward you.
216 FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016)
