Adva FSP 3000 - Network Interface; Client Port Channel Assignments

FD-128D
Network Interface
Number of network ports 1 Txand 1 Rx
Type of network interface Bi-directional optical
Optical connector LC/PC
Fiber type SM G.652
Client Port Channel Assignments
On the faceplate, each client port is labeled with the port number (C1 to C128), as well as
the corresponding supported frequency in GHz. Each client port has a transmit and
receive connector, which has the same number as the client port. For example, the C1
client port has both a transmit (C1-T) and receive (C1-R) connector. The following table
provides details about each client port.
Client ports
FSP 3000 C
Channel Names
(GHz)
Frequencies (MHz)
Frequencies
(THz)
Wavelengths
(nm)
C1 19600 196000000 196.00 1529.55
C2 19596 195962500 195.96 1529.84
C3 19592 195925000 195.92 1530.13
C4 19588 195887500 195.88 1530.43
C5 19585 195850000 195.85 1530.72
C6 19581 195812500 195.81 1531.01
C7 19577 195775000 195.77 1531.31
C8 19573 195737500 195.73 1531.60
C9 19570 195700000 195.70 1531.89
C10 19566 195662500 195.66 1532.19
C11 19562 195625000 195.62 1532.48
C12 19558 195587500 195.58 1532.77
C13 19555 195550000 195.55 1533.07
C14 19551 195512500 195.51 1533.36
C15 19547 195475000 195.47 1533.66
C16 19543 195437500 195.43 1533.95
C17 19540 195400000 195.40 1534.25
C18 19536 195362500 195.36 1534.54
C19 19532 195325000 195.32 1534.83
C20 19528 195287500 195.28 1535.13
C21 19525 195250000 195.25 1535.42
C22 19521 195212500 195.21 1535.72
C23 19517 195175000 195.17 1536.01
C24 19513 195137500 195.13 1536.31
