Required Tools and Equipment
Required Tools and Equipment
l ESD-preventive wrist strap or other personal grounding device
l Rack (used in previous procedure)
l Rack screws and cage nuts for attaching the FSP 3000 C shelf to the rack
l Appropriate guide rail kit (for SH4R)
o
2 x guide rails
o
12 x M6x20 screws (8 for attaching guide rails to rack and 4 for rack mounting the
SH4R)
o
2 x guide rail brackets and 8 M3x6 screws (for 23-inch rack installation — included
in SH4R mounting bracket kit)
l Pozidriv screwdriver
l 1 x cage nut in conjunction with a Pozi screw (both included in with the
ADVAgrounding cable) to attach the grounding cable to the rack (if applicable)
l Multimeter (for testing grounding cable)
l Installation Overview — SH12 and SH4R Shelves
l Installation Overview — 4U Shelf
l Installation Overview — 1U Shelf
l Guide Rail Kits
l Racks
l Rack-Mounting Requirements and Warnings
l Site Preparation Checklist
l Electrostatic Discharge Damage Prevention and Warning
Mounting the SH12 Shelf to a Rack
LIFTINGHAZARD CAUTION
ADVA Optical Networking recommends having two people hold the shelf
in place while a third person secures it to the rack.
This procedure assumes that:
l The mounting brackets have been attached to the shelf;
l A cover extension is installed (if applicable); and
l The grounding cable has been installed to the shelf.
1. Verify that you are properly grounded with an anti-static wrist strap or heel strap
connected to the grounded ESD jack.
2. On the rack mounting rails, locate and mark the mounting holes where you will mount
the shelf.
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 205
