Grounding Cables
If you plan to have a front cover installed on your FSP 3000 C shelf and
will be using cables with MPOconnectors, you must have the front cover
extension installed. To determine if your shelf rack/cabinet configuration
supports front covers and extensions, as well as more information about
accessory installation requirements, see Accessory Installation
Requirements.
The following figures provide cable management examples.
Figure 34: SH4R Cable Management Example — Front View
Figure 35: SH4R Cable Management Example — Top View
l Breakout Cables
l FMT/1HU Shelf
l Connecting the Optical Cables
Grounding Cables
Grounding Cable — SH12 155
Grounding Cable — SH4R 155
