Features
l Storage radius limiters and rear radius limiters protect the fiber cables from bend-
induced losses
l Modular extensible design, based on the 19-inch format
l Robust, low-profile housing made from alloyed steel sheet
l Access to the fiber optic tray from the front of the shelf
l Cable Management Best Practices
l SH12 Shelf
l SH4R Shelf
l Overview
Cable Capacity
The number of cables that can be stored in the FMT/1HU depends on the cable
dimensions and lengths. The following table provides maximum recommended values
based on the dimension and length of the cable. The maximum cable number can only be
stored in the shelf when the cables are guided carefully in parallel without crossing and is
applicable to each side (incoming and outgoing) of the FMT/1HU.
Dimension
Stored Fiber Length
1
(Min. to Max.)
Max. Cable
Number
3 mm (0.118 in.)
45 cm (17.717 in.) to 145 cm (57.086 in.) 26 cables
146 cm (57.48 in.) to 240 cm (94.488 in.) 15 cables
241 cm (94.882 in.) to 340 cm (133.858 in.) 11 cables
2 mm (0.079 in.)
2
45 cm (17.717 in.) to 145 cm (57.086 in.) 60 cables
146 cm (57.48 in.) to 240 cm (94.488 in.) 35 cables
241 cm (94.882 in.) to 340 cm (133.858 in.) 25 cables
1.7 mm (0.069 in.)
45 cm (17.717 in.) to 145 cm (57.086 in.) 83 cables
146 cm (57.48 in.) to 240 cm (94.488 in.) 48 cables
241 cm (94.882 in.) to 340 cm (133.858 in.) 35 cables
Table 60: Recommended Values for the Capacity of the FMT/1HU
Considering all cable dimensions, a minimum length of 45 cm (17.717 in.) of fiber can be
stored in the FMT/1HU when it is laid directly from one sliding radius limiter to the other.
124 FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016)
