Adva FSP 3000 - Number of DC Power Cables; Cbl;DC;0300;4 Awg10;Sub-D

Power Cables
The actual length of each DC power cable depends on the location of the
shelf within the rack and its proximity to the DC power source. Therefore,
each power cable should be cut to the proper length and have the
appropriate connectors.
As the customer, you are responsible for assembling the appropriate
terminal connectors at the wiring end that is attached to the external DC
power source.
The separate multiple-wire stranded copper conductor should not be
twisted or plaited as that would reduce the ampacity of the cable.
l Power
l PSM-DC
l DC Power Electrical Safety Guidelines and Warnings
l Providing Power to the Shelves
Number of DCPower Cables
The number of cables needed with an SH12 shelf depends on how many PSM-DCs you
are installing and which power feeds you are using (Power A and/or Power B).
l A feed only with 1 or 2 PSM-DCs — 1 cable needed
l A feed only with 3 or 4 PSM-DCs — 2 cables needed
l A+B feed with 1 or 2 PSM-DCs — 2 cables needed
l A+B feed with 3 or 4 PSM-DCs — 4 cables needed
l Power
l PSM-DC
l DC Power Electrical Safety Guidelines and Warnings
l Providing Power to the Shelves
CBL/DC/0300/4AWG10/SUB-D
The CBL/DC/0300/4AWG10/SUB-D is a flexible DC power cable which includes four
separate multiple-wire stranded copper conductors with a cross section area of each 5.3
mm
2
(10 AWG). The conductors are surrounded by resistant color-coded plastic
insulation, which is different for each of the three cable variants.
Cable Type DCPower Cable
Compatible
Components
l SH12
o
PSM-DC
