Adva FSP 3000 - Interfaces; Client Interface; Interconnect Interface; Monitor Interface

FD-128D
Interfaces
Client Interface 83
Interconnect Interface 83
Monitor Interface 83
Network Interface 84
l Overview
l Cables
l Specifications
Client Interface
Number of client ports 128 Tx and 128 Rx
Type of client interface Bi-directional optical
Optical connector LC/PC
Fiber type SM G.652
Interconnect Interface
Number of interconnect
ports
1
Electrical connector type FireWire (6-pins)
Cable type IEEE 1394 Interface Cable
Signals
l I2C (2 pins)
l Shelf detect (1 pin)
l Power (3V3 and ground, 2 pins)
1
Even though some FSP 3000 C components use FireWire connectors for
interconnecting, neither the FireWire protocol nor pinning is supported.
1
one free pin
Monitor Interface
Number of monitor ports 2
Type of monitor interface Uni-directional for input (Mon N-R) and output (Mon N-T)
Optical connector LC/PC
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 83
