Required Tools and Equipment
l The dedicated power source outlets are easily accessible and located close to the
PSMs. The supplied AC power cables are approximately 2.5 m (8.203 ft) long.
l The line voltage and frequency to be used are the same as indicated on the shelf
supply values label located on the SH4R.
l The plug-socket combinations must be accessible at all times, because they serve as
the main disconnecting device in case of an emergency.
l AC Power Cable Specifications
l AC Power Source Requirements
l General Power and Grounding Guidelines
l Site Planning and Preparation
l Connecting ACPower to theSH4R Shelf
Required Tools and Equipment
To shorten and assemble DC power cables (optional)
l ESD-preventive wrist strap or other personal grounding device
l Two or four DCpower cables of the proper length, depending on which redundant,
load-sharing mode configuration you want to support (provided by ADVA Optical
Networking but have to be ordered separately)
l Appropriate terminal connectors to match the connectors on the external power source
l Tape measure
l Wire cutter
l Wire stripper
l Wire crimping tool
You must use the ADVA Optical Networking provided power cables.
To connect the DCpower cables to the shelf
l ESD-preventive wrist strap or other personal grounding device
l Two or four DCpower cables of the proper length, depending on which redundant,
load-sharing mode configuration you want to support (prepared in Shortening and
Assembling DCPower Cables)
l Torx T10 screwdriver
l Phillips screwdriver size 1
l Appropriate screwdriver or spanner for the terminal screws of the DC power source,
e.g. a PDU
232 FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016)
