AM-S20H-2
Section Parts of the Name Value Meaning
B Amplifier type
Note:In case of Hybrid amplifier,
the EDFA section is designated
first.
S Single-stage EDFA
D Double-stage EDFAwith mid-stage access
R Raman
Power or gain range n Power range (in dBm) for EDFA or gain range
(indB) for Raman
Amplifier type and power/gain
range
(if applicable)
For hybrid and dual amplifiers
Gain range H High gain
L Low gain
C Variant — Part 1 M Metro
E Enterprise
A AES Encryption
P Passive filters (not slide in modules)
none General or Core
L L-Band
TD Tunable Dispersion Compensation
Variant — Part 2 n > 1 Number in development sequence. The first
variant of a module does not have a number.
Table 25: Amplifier Module Naming Convention
l Overview
l Traffic Module Compatibility
AM-S20H-2
Overview 65
Features 66
Interfaces 67
Signal Path 69
Specifications 69
Overview
The AM-S20H-2 is an EDFA-type optical amplifier with a variable high gain supporting
amplification of up to 128 channels in the C-band.
