Mounting a 4U or 1U Shelf to a Rack
l Installation Overview — SH12 and SH4R Shelves
l Supported Rack Requirements
l Installing the Mounting Brackets
l Shelf Lifting and Moving Guidelines
l Rack-Mounting Requirements and Warnings
l Handling Equipment Precautions and Guidelines
l Electrostatic Discharge Damage Prevention and Warning
Mounting a 4U or 1U Shelf to a Rack
In this procedure, 4U shelf refers to the FD-128D. For procedures for the
SH4R, see Mounting the SH4R Shelf to a Rack.
This procedure assumes that:
l The mounting brackets have been attached to the shelf; and
l The FMT/1HU has to be installed under or above the FSP 3000 C to
store the fibers of that shelf.
1. Verify that you are properly grounded with an anti-static wrist strap or heel strap
connected to the grounded ESD jack.
2. On the rack mounting rails, locate and mark the mounting holes where you will mount
the shelf.
3. Install two or four cage nuts in the corresponding holes on both sides of the rack.
4. Mount the shelf to the rack:
a. With a person on each side, lift the shelf to the bay and position it in the rack so
that the bracket holes on each side are aligned with the rack mounting holes or
the cage nuts.
b. Use a Pozidriv screwdriver and 2 screws to attach the left mounting bracket to
the rack.
c. Use a Pozidriv screwdriver and 2 screws to attach the right mounting bracket to
the rack.
5. Repeat this procedure for installing additional shelves in the rack.
l Installation Overview — 1U Shelf
l Installation Overview — 4U Shelf
l Installing the Mounting Brackets
l Shelf Lifting and Moving Guidelines
l Rack-Mounting Requirements and Warnings
l Handling Equipment Precautions and Guidelines
l Electrostatic Discharge Damage Prevention and Warning
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 209
