Adva FSP 3000 - Features; Interfaces

FD-128D
Parameter Value Notes
Environmental standards
compliance
l Telcordia SR-3580 level 3 (NEBS),
l ETSI EN 300-019-1-2 class 1.2 and 2.3,
l ETSI EN 300 019-1-3 Class 3.1
l IEC 60529 IP20 (indoor office)
Table 36: General Information — FD-128D
l Environmental Specifications
l MTBF Hours for FSP 3000 C Equipment
l Traffic Module Compatibility
l Slot Numbers and Assignments — SH12
l Slot Numbers and Assignments — SH4R
l Specifications
Features
l Supports up to 128 C-band channels (wavelengths) on the 37.5 GHz grid according to
ITU-T G.694.1 and ADVA Optical Networking channel plan
l Ultra-fast transient suppression
l Provides the following ports and indicators
o
One LC/PC bi-directional optical network port — Input and output for the C-band
channel spectrum
o
128 LC/PC bi-directional client ports — Input and output for a specific C-band
channel
o
Two uni-directional monitor ports for input (N-R) and output (N-T)
o
One management interconnect port for passive shelf management and power
o
Two-color module (P) LED
l Has five fiber management guides to keep the fiber cables organized, allowing for
quick and easy installation or removal
l Powered via internal management interface to a CEM-2 or CEM-4 with non-redundant
nominal 3V3DC feed
l Is transport protocol independent
l Has front-accessible ports and connectors
l Provides full management support when connected to a CEM-2 or CEM-4
l Provides shelf fault management through the CEM-2 or CEM-4
l Includes easy-to-remove front cover is placed to protect the fiber optic connectors
against external influences and prevents the fibers from being pulled out inadvertently
l Is field replaceable
l Interfaces
l Signal Path
l Client Port Channel Assignments
l Handling Modules
l Electrostatic Discharge Damage Prevention and Warning
