Adva FSP 3000 - Features

SH4R Shelf
Parameter Value Notes
Maximum power
1+0 (non-redundant)
configuration)
l 870 W @ 100 to 240 VAC
l 8.7 A @ 100 VAC
l 7.3 A @ 120 VAC
l 3.6 A @ 240 VAC
1+1 (redundant) configuration
l 1304 W @ 100 to 240 VAC
l 13.0 A @ 100 VAC
l 10.9 A @ 120 VAC
l 5.4 A @ 240 VAC
2+0 (non-redundant) and 2+1
(redundant) configurations
l 1533 W @ 100 to 240 VAC
l 15.3 A @ 100 VAC
l 12.8 A @ 120 VAC
l 6.4 A @ 240 VAC
Maximum internal power
l 1+0: 800 W
l 1+1:1200 W
l 2+0 and 2+1:1410 W
Environmental standards
compliance
l Telcordia SR-3580 Level 3 (NEBS)
l ETSI EN 300 019-1-3 Class 3.1
l IEC 60529 IP20 (indoor office)
Table 4: General Information — SH4R
l Environmental Specifications
l Power
l MTBF Hours for FSP 3000 C Equipment
l Infrastructure Modules
l Traffic Module Compatibility
l Accessories
l Installation Overview — SH12 and SH4R Shelves
l Permissible Configurations
Features
l Provides high-density support for all traffic modules
l Has both a front and rear access architecture
l Supports 2-zone ground configuration
l Provides electrical connections for power supply and intrashelf communication via the
backplane
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 33
