SH4R Shelf
Parameter Value Notes
Weight 22.6 kg (49.9 lbs) Measured with
l Two FTM-4s
l One CEM-4
l Two ECM-2s
l Three PSM-AC4s
l Front cover
l Slot covers
Number of slots 9
l 2 for management modules
l 7 for traffic modules
Power Power Supply Module
(PSM-AC4)
l Supports up to three AC/DC PSMs
l Supports redundant configurations: 1+1
and 2+1
l Supports non-redundant configurations:
1+0 and 2+0
Cooling Fan Tray Module (FTM-4)
l Supports two FTM-4s for redundancy
Management
l Common Equipment
Module (CEM-4)
l Element Controller Module
(ECM-2)
Rack format support
l 19-inch
l 23-inch
Shelf comes with 19-inch mounting
brackets. Other brackets can be ordered
separately.
Temperature range 5 to 40°C (41 to 104°F) Long term
–5 to 50°C (23 to 122°F) Short term, testing to 55°C (131°F)
Humidity 85% at 40°C (104°F) Long term
5 to 93% Short term
Altitude 5000 m (16,404.2 ft)
Nominal/rated input voltage 100 to 240 VAC
Voltage tolerance
l Nominal/Rated:100 to 240
VAC
l Operating: 90 to 264 VAC
Nominal/rated current
l 1+0: 8.7 to 3.6 A @ 100 to
240 VAC
l 2+0 and 2+1: 15.3 to 6.4 A
@ 100 to 240 VAC
l 1+1: 13.0 to 5.4 A @ 100 to
240 VAC
Power consumption
(fully equipped with 7 traffic
modules)
1035 W @ 100 to 240 VAC Typical
1533 W @ 100 to 240 VAC Maximum
Table 4: General Information — SH4R
32 FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016)
