Adva FSP 3000 - Connecting the Infrastructure Modules; Required Tools and Equipment Connecting the Infrastructure Modules

Required Tools and Equipment
Chapter 26
Connecting the Infrastructure Modules
Required Tools and Equipment 227
Connecting the Infrastructure Modules 227
Required Tools and Equipment
l ESD-preventive wrist strap or other personal grounding device
l Appropriate Ethernet cables
l Appropriate USB cable (if applicable)
l IEEE 1394 Interface Cable (if configuration uses FD-128D)
l Installation Overview — SH12 and SH4R Shelves
l Infrastructure Modules
l Cables
l Handling Modules
Connecting the Infrastructure Modules
This procedure assumes that:
l The ECM-2 and CEM have been installed correctly; and
l The traffic modules and pluggable transceivers have been installed
correctly.
1. Verify that you are properly grounded with an anti-static wrist strap or heel strap
connected to the grounded ESDjack.
2. Select the correct cable types (according to your installation plan).
3. Connect the FSP 3000 C infrastructure modules according to the appropriate cabling
diagram.
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 227
