Building Structure Connection for Rack
l SH12 Shelf
l SH4R Shelf
l Clearance Requirements
l Mounting Bracket Kits
l Guide Rail Kits
l Accessory Installation Requirements
1
Use only the front two posts for installation
2
To support rear-mounted grounding
Building Structure Connection for Rack
Always secure the rack to the structure of the building. If your geographical area is
subject to earthquakes, bolt the rack to the floor. For maximum stability, also secure the
rack to ceiling brackets.
l Installation Overview — SH12 and SH4R Shelves
l Supported Rack Requirements
l Site Preparation Checklist
Clearance Requirements
When planning the installation site, you need to allow sufficient clearance around the rack
for installation and maintenance. It is also important to have sufficient airflow clearance
during system operation. Without it, the ambient air temperature may not cool the FSP
3000 C equipment to admissible operating temperatures. Excessive operating
temperatures can cause malfunctions and emergency shutdowns of the system.
As you plan your installation site, adhere to these guidelines to ensure proper airflow
around the FSP 3000 C equipment.
CAUTION
Failure to follow these guidelines can cause overheating and a fire
hazard, as well as affect the reliability and warranty of your equipment.
l Ensure that intake air to the FSP 3000 C system is cooled by the installation site air
conditioning system and is as dust free as possible.
l Verify that the intake air enters and exits the shelf at the proper location and that the
airflow around the shelf is unrestricted.
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 145
