Adva FSP 3000 - Signal Path; Specifications

FD-48E
Signal Path
The following figure provides a simplified functional block diagram illustrating the FD-48E
signal path.
l Overview
l Features
l Interfaces
Specifications
The following tables provide the optical specifications from the client port to the network
port.
Insertion loss Maximum:6.0 dB
Passband width >200 pm
Table 34: Optical Characteristics — Multiplexer
Insertion loss Maximum:6.0 dB
Table 35: Optical Characteristics — Demultiplexer
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 79
