Mounting Bracket Kits
Mounting Bracket Kits
Shelf Mounting Bracket Kit
Sales Item
Number
SH4R
F8/SA-BRACKET-SH4: Includes 23-inch rack mounting
brackets and guide rail brackets for the guide rail kit
installation
1013800059-01
Table 57: Available Mounting Bracket Kits
The SH12 and SH4R ship with the 19-inch mounting brackets
preinstalled.
The mounting brackets for the SH12, FMT/1HU, and FD-128D ship with
each shelf and are not ordered separately.
l Supported Rack Requirements
l Clearance Requirements
l Installing the Mounting Brackets
Shelf Front Covers
The shelf front covers protect the fiber-optic cabling. The following front covers come
with the FSP 3000 C shelves.
Shelf Front Cover
SH12 F8/SA-FC-SH12 (upper and lower covers)
SH4R F8/SA-FC-SH4
FD-128D N/A
If you plan to have a front cover installed on your FSP 3000 C shelf and
will be using cables with MPOconnectors, you must have the front cover
extension installed. To determine if your shelf rack/cabinet configuration
supports front covers and extensions, as well as more information about
accessory installation requirements, see Accessory Installation
Requirements.
The lower front cover houses an air filter for the PSM-DCs and it must be
installed.
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 119
