Replacing an FTM
Replacing an FTM
Required Tools and Equipment 281
Replacing an FTM-2 281
Replacing an FTM-4 282
A malfunctioning FTM can be replaced while the shelf is in service. It is
recommended to have a spare FTM available at all times.
When one of the FTMs is malfunctioning or has failed, it must be
replaced within 48 hours after failure. To restore system cooling,
ensure that the replacement procedure does not exceed three
minutes.
Required Tools and Equipment
l ESD-preventive wrist strap or other personal grounding device
l Suitable grounded surface or a static-dissipative mat
l Appropriate FTM for FSP 3000 C shelf
o
FTM-2 for SH12
o
FTM-4 for SH4R
l Torx T10 screwdriver
l Electrostatic Discharge Damage Prevention and Warning
l Handling Modules
l General Installation and Maintenance Guidelines
l Maintenance and Operational Safety Guidelines and Warnings
Replacing an FTM-2
This procedure assumes that:
l The shelf is properly grounded to the rack; and
l The replacement module has been unpacked and properly inspected.
1. Verify that you are properly grounded with an anti-static wrist strap or heel strap
connected to the grounded ESDjack.
2. If mounted, remove the front cover from the shelf as described in Removing and
Installing Front Covers.
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 281
