Power Cables
Grounding Cable — SH12
The SH12 ships with the following grounding cable:
l Shelf grounding cable — 4 AWG, 100 cm length, green/yellow with 2-hole straight ring
lugs at both ends (5 mm [0.2 in.] hole). Appropriate screws and washers are included.
l Grounding
l General Power and Grounding Guidelines
l Connecting the Grounding Terminals
l Electrical Safety Guidelines and Warnings
Grounding Cable — SH4R
The SH4R ships with the following grounding cable:
l Shelf grounding cable — 6 AWG, 100 cm length, green/yellow with 2-hole ring lugs at
both ends (5 mm [0.2 in.] hole). Equipment end: 90-degree angled. Rack end: straight.
Appropriate screws and washers are preinstalled on the shelf.
l Grounding
l General Power and Grounding Guidelines
l Connecting the Grounding Terminals
l Electrical Safety Guidelines and Warnings
Power Cables
DC Power Cable Specifications 155
AC Power Cable Specifications 158
DC Power Cable Specifications
Overview 155
Number of DCPower Cables 156
CBL/DC/0300/4AWG10/SUB-D 156
CBL/DC/1000/4AWG8/SUB-D 157
Overview
The type of power cables used depends on the type of DC power supplies and the
voltages used.
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 155
