SH4R Shelf
l Supports hot-swapping of all modules
l Cools through airflow passing from front input to rear output
l Provides a replaceable air filter
l Provides shelf status LEDs for identification and easy troubleshooting
l Offers front fiber routing using the fiber interconnects
Keep fiber-optic cables organized. If you do not use your rack posts for
fiber management, ADVA Optical Networking strongly recommends
using the FMT/1HU.
l Overview
l Traffic Module Compatibility
l Handling Fiber-Optic Cables
l Agency Approvals and Regulatory Compliance Information
Slot Numbers and Assignments
The slot numbers indicate where the modules may be installed in the
shelf and are not used when configuring the system via the software.
Slot Module
1 through 7 Traffic modules
21 and 22 ECM-2s
31 CEM-4
33 and 34 FTM-4s
35 through 37 PSMs
Table 5: Slot Assignments — SH4R
34 FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016)
