Prerequisites for Connecting the DC Power
Prerequisites for Connecting the DC Power
ELECTRIC VOLTAGEWARNING
Only service personnel or a qualified/licensed electrician are
allowed to connect DC power cables.
l The site wiring systems must be installed in accordance with your national and local
electrical safety standards.
l Site wiring must include a protective ground connection to the –48 VDC power source.
l A properly rated two-pole circuit breaker or single pole fuse is required between each
DC power source and each PSM of the shelf for over-current and short-circuit
protection. They must be incorporated into the site wiring system. The circuit breaker
or single pole fuse also serves as a disconnect device and must be readily accessible
at all times.
l Each PSMor power feed must use a separate power source, maintaining power
redundancy.
l When connecting dual DC power sources, both sources must have the same polarity.
l One customer-supplied power distribution unit (PDU) has been installed at the top of
each rack and office battery power and return cables are connected to the PDU.
l The PDU must provide power nominally at –48 VDC to each shelf. You are
responsible for supplying and wiring the PDU to the power connections of the shelf.
l The equipment rack and the PDU have been grounded by a safety ground wire in
accordance with local procedures.
l The DC power cables used must meet applicable standards for safety and
performance. The DC power cables must have wires of the proper size and must be of
the proper length. Make sure that the supply end of each cable is suitably prepared.
l Vertical cable management brackets have been mounted on the front sides of the rack,
providing secure cable storage and cable protection.
l DC Power Cable Specifications
l DCPower Source Requirements
l General Power and Grounding Guidelines
l Site Planning and Preparation
l Connecting DC Power to the SH12 Shelf
Prerequisites for Connecting the AC Power
l The site wiring systems must be installed in accordance with your national and local
electrical safety standards.
l Site wiring must include a protective ground connection to the ACpower source.
l The PSM-AC4 should be the only appliance in the supply circuit.
l Each PSMmust use a separate AC power source outlet, maintaining power
redundancy.
FSP3000 C Hardware Guide - R1.1 - Issue:A (12/09/2016) 231
